TP-Link EAP650-Desktop Omada AX3000 Desktop Wi-Fi 6 Access Point | T85

Description Model: EAP650-Desktop TP-Link​​ Omada AX3000 Desktop Wi-Fi 6 Access Point Blazing-Fast AX3000 WiFi 6 Speeds: 574 Mbps on 2.4 GHz and 2402 Mbps on 5GHz totals 2976 Mbps WiFi speeds. † Multiple Gigabit Ports: Connect multiple devices with 4× Gigabit Ethernet Ports. Convenient Deployment: Supports both 802.3bt PoE and DC (adapter included) for easy and quick deployment. No Installation needed:Supports desktop installation without the need for additional setup. High Flexibility: Provide flexible installation solutions for both desktop and wall mounting. Stay Smooth with Seamless Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points.§ Centralized Cloud Management: Integrates with the Omada SDN platform for Centralized Management. § Specifications HARDWARE FEATURES Interface 4× 1Gbps Ethernet Ports 1× FXS Port (One Ethernet port supports PoE Out: 802.3at/af output at 802.3bt input, 802.3af class 2 output at 802.3at input) Button • Reset • LED Power Supply 802.3 af/at/bt PoE or 12V/1.5A DC *PoE Out requires 802.3at/bt PoE power supply Max. Power Consumption 17.3W (PoE Out Off) Weight 452g (excluding mounting base) Dimensions ( W x D x H ) 6.9 × 5.5 × 1.3 in (175 × 140 × 33 mm) Antenna Internal Omni • 2.4 GHz: 2× 5 dBi • 5 GHz: 3× 4.7 dBi Range 140㎡(1500 ft²)* Mounting Desktop / Wall mouting (Kits included) WIRELESS FEATURES Concurrent Clients 250 * Wireless Standards IEEE 802.11 a/b/g/n/ac/ax Frequency 2.4 GHz and 5 GHz Signal Rate • 5 GHz: 2402 Mbps† • 2.4 GHz: 574 Mbps Wireless Functions • 2×2 (2.4G & 5G) MU-MIMO‡ • HE160 (160 MHz Bandwidth)‡ • OFDMA‡ • Seamless Roaming § • Multiple SSIDs (16 SSIDs, 8 on each band) • Enable/Disable SSID Broadcast • Enable/Disable Wireless Radio • Guest Network • Automatic Channel Assignment • Beamforming • Rate Limit (Based on SSID/Client) • Band Steering • Load Balance • Airtime Fairness • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • RADIUS Accounting • MAC Authentication • Reboot Schedule • Wireless Schedule and Statistics • Static IP/Dynamic IP Wireless Security • Captive Portal Authentication§ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • VLAN • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise Transmission Power • CE: <20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, band1 & band2, EIRP) <29 dBm(5 GHz, band3, EIRP)• FCC: <26 dBm (2.4 GHz) <27 dBm (5 GHz) Management Features Omada App Yes Centralized Management • Omada Hardware Controller • Omada Software Controller • Omada Cloud-Based Controller Cloud Access Yes. Email Alerts Yes LED ON/OFF Control Yes Management MAC Access Control Yes SNMP v1, v2c, v3 System Logging Local/Remote Syslog System Log SSH Yes Web-based Management Yes Zero-Touch Provisioning Yes.Reauire the use of Omada Cloud-Based controller OTHERS Certification CE, FCC, RoHS, IC Package Content • EAP650-Desktop • Desktop/Wall Mounting Kit • Installation Guide System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux Environment • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing Related
