TP-Link TL-WA3001 AX3000 Gigabit Wi-Fi 6 Access Point | T60

Description Model: TL-WA3001 TP-Link AX3000 Gigabit Wi-Fi 6 Access Point Overview Gigabit WiFi 6 Speed for 4K Streaming – 3000 Mbps Dual Band WiFi for faster browsing, streaming and downloading, all at the same time. Flexible Deployment – Supports Passive PoE to carry electrical power and data simultaneously. Multiple Modes – Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs. Boosted Coverage – Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals. Captive Portal – Offers a designed portal page for heightened security and marketing. Specifications HARDWARE FEATURES Interface 1 Gigabit Port (Supports Passive PoE) Button Power On/Off Button, WPS Button, Reset Button External Power Supply 48V/0.5A Dimensions ( W x D x H ) 9.4×6.5×1.7 in (240×165×43.6mm) Antenna 4 Fixed High Performance Antennas WIRELESS FEATURES Wireless Standards IEEE802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz Frequency 2.4 GHz and 5 GHz Signal Rate 2402 Mbps at 5 GHz, 574 Mbps at 2.4 GHz Reception Sensitivity 5 GHz: 11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm 11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm 11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm 11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm 2.4 GHz: 11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm 11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm Wireless Functions Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control Wireless Security WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions Transmission Power FCC: <23dBm(2.4GHz), <22dBm(5GHz) SOFTWARE FEATURES Quality of Service WMM Operating Modes Access Point, Range Extender, Client, Multi-SSID System Tools SNMP, Ping Watchdog DHCP Server, DHCP Client List Protocols IPv4, IPv6 OTHER Network Services Enabled by Default Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443   Protocol: TCP DNS DNS • Port: 53   Protocol: TCP & UDP DHCP Server IP address assignment (DHCP) • Port: 67   Protocol: UDP App management Manage and configure device through app • Port: 20001   Protocol: TCP • Port: 30001   Protocol: TCP • Port: 20002   Protocol: UDP OTHERS Certification FCC, RoHS Package Content Wireless Access Point TL-WA3001 Power Adapter RJ45 Ethernet Cable Quick Installation Guide PoE Power Injector System Requirements Internet Explorer 11 , Firefox 12.0 , Chrome 20.0 , Safari 4.0 , or other JavaScript-enabled browser Environment Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F) Operating Humidity: 10%~90% non-condensing Related
